| Thermal |
| Detector Type |
Vanadium oxide uncooled focal plane detector |
| Effective Pixels |
400 (H) × 300 (V) |
| Pixel Pitch |
17 μm |
| Spectral Range |
8 μm–14 μm |
| Sensitivity (NETD) |
≤35 mK (@f/1.0) |
| Focal Length |
7.5 mm; 13 mm; 25 mm; M25 mm; 50 mm |
| Field of View |
7.5 mm: H: 53.7°; V: 39.7°
13 mm: H: 30.0°; V: 22.6°
25 mm/M25 mm: H: 15.5°; V: 11.6°
50 mm: H: 7.8°; V: 5.8° |
| Thermal Focus Control |
7.5 mm: Athermalized
13 mm: Athermalized
25 mm: Athermalized
M25 mm: Auto/semi-auto/Manual
50 mm: Athermalized |
| Close Focus Distance |
7.5mm: 1 m (3.28 ft)
13 mm: 2.5 m (8.2 ft)
25 mm: 10 m (32.81 ft)
M25 mm: 0.5 m (1.64 ft)
50 mm: 40 m (131.23 ft) |
| Detection Distance? |
7.5 mm: Vehicle: 679 m (2,226.81 ft);
Human: 221m (725.1 ft)
13 mm: Vehicle: 1,176 m (3,859.81 ft);
Human: 382 m (1,253.28 ft)
25 mm/M25mm: Vehicle: 2,262 m (7,422.71 ft);
Human: 735 m (2,411.42 ft)
50 mm: Vehicle: 4,525 m (14,845.43 ft);
Human: 1,470 m (4,822.83 ft) |
| Recognition Distance? |
7.5 mm: Vehicle: 166 m (546.20 ft);
Human: 57m (187 ft)
13 mm: Vehicle: 289 m (946.75 ft);
Human: 98 m (321.52 ft)
25 mm/M25mm: Vehicle: 555 m (1,820.67 ft);
Human: 189 m (620.08 ft)
50 mm: Vehicle: 1,110 m (3,641.33 ft);
Human: 378 m (1,240.16 ft) |
| Identification Distance? |
7.5 mm: Vehicle:Vehicle: 84 m (275.70 ft);
Human: 28m (91.9 ft)
13 mm: Vehicle: 146 m (477.88 ft);
Human: 49 m (160.76 ft)
25 mm/M25mm: Vehicle: 280 m (919.00 ft);
Human: 95 m (311.68 ft)
50 mm: Vehicle: 560 m (1,838.01 ft);
Human: 189 m (620.08 ft) |
| Note:
?Detection Distance: Detects objects, but cannot recognize their characteristics
(objects must cover more than 3.6 pixels of the image).
?Recognition Distance: Classifies objects into general categories, such as
human, vehicle (the object must cover more than 14 pixels of the image).
?Identification Distance: Classifies objects into specific categories based on
their characteristics, such as engineering truck, car (the object must cover
more than 28 pixels of the image). |
| Digital Detail Enhancement (DDE) |
Yes |
| Thermal Image Stabilization |
Electronic Image Stabilization (EIS) |
| Digital Zoom |
19 levels |
| Thermal AGC |
Auto/Manual |
| Thermal Noise Reduction |
2D NR/3D NR |
| Image Flip |
180° |
| Color Palettes |
18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter) |
| Temperature Measurement Range |
Low temperature mode: –20 °C to +150 °C (–4 °F to +302 °F)
High temperature mode: 0 °C to +550 °C (+32 °F to +1022 °F)
Auto mode: –20 °C to +550 °C (–4 °F to +1022 °F) |
| Temperature Measurement Accuracy |
Max. (±2 °C, ±2%);
Operating temperature: –20 °C (–4°F) to
+60 °C (+302 °F) |
| Temperature Measurement Mode |
Spot: 12
Line: 12
Area: 12
Supports 12 rules simultaneously |
| Visible |
| Image Sensor |
1/1.8″ CMOS |
| Max. Resolution |
2688 (H) × 1520 (V) |
| Pixel |
4 MP |
| Horizontal Definition |
≥1200 TVL |
| Min. Illumination |
Color: 0.001 [email protected]
Black & white: 0.0001 [email protected]
0 lux (IR on) |
| Visible AGC |
Auto/Manual |
| Visible Noise Reduction |
2D NR/3D NR |
| S/N Ratio |
>55 dB |
| White Balance |
Auto; manual; indoor; outdoor; tracking; sodium lamp; street lamp; natural |
| Defog |
Optical defog |
| Electronic Shutter Speed |
1 s–1/30,000 s (auto/manual) |
| BLC |
Yes |
| WDR |
Yes |
| HLC |
Yes |
| Day/Night |
Auto (ICR); Color; B/W |
| Iris Control |
Auto |
| Image Flip |
180° |
| Exposure Compensation |
Yes |
| Visible Focus Control |
Auto/semi-auto/manual |
| Focal Length |
5.5 mm–248 mm |
| Field of View |
H: 67.5°–1.9°
V: 39.4°–1.1° |
| Close Focus Distance |
0.5 m–2 m (1.64 ft–6.56 ft) |
| Illuminator On/Off Control |
Auto/Manual |
| Illumination Distance |
100 m (328.08 ft, IR)
50 m (164.04 ft, white light) |
| Audio and Video |
| Video Compression |
H.265; H.264M; H.264H; H.264B |
| Resolution |
Thermal:
Main stream: 1280 × 1024; 1280 × 960; 1280 × 720; 400 × 300; 1280 × 1024 (default)
Sub stream: 640 × 512; 640 × 480; 400 × 300; 400 × 300 (default)
Visible:
Main stream: 2688 × 1520; 2560 × 1440; 1920 × 1080; 1280 × 720; 704 × 576; 352 × 288; 2688 × 1520 (default)
Sub stream: 1280 × 720; 704 × 576; 352 × 288; 352 × 288 (default) |
| Video Frame Rate |
Thermal:
50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default
60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default
Visible:
50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default
60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default |
| Audio Compression |
G.711a; G.711mu; PCM |
| Image Encoding Format |
JPEG |
| PTZ |
| Pan/Tilt Range |
Pan: 0° to 360° endless
Tilt: –90° to +90° |
| Manual Control Speed |
Pan: 0.1°/s –100°/s
Tilt: 0.1°/s –80°/s |
| Preset Speed |
Pan: 0.1°/s –100°/s
Tilt: 0.1°/s –80°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Power-off Memory |
Yes |
| Privacy Masking |
4 areas in the same view |
| Idle Motion |
Preset; auto pattern; auto tour; pan; progressive scan |
| Function |
| Two-way Audio |
Yes |
| Network Protocol |
HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS;
UPnP; NTP; Multicast; SFTP; 802.1x |
| Region of Interest (RoI) |
Yes |
| Storage |
FTP; Micro SD card (optional) |
| Micro SD Card (Max.) |
512 GB |
| Interoperability |
ONVIF; CGI; Dahua SDK |
| Browser |
IE: IE8 and later
Chrome: 42 and earlier
Firefox: 42 and earlier |
| User/Host |
Up to 12 (total bandwidth: 64 MB) |
| Security |
Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access |
| User Management |
Up to 20 users; supports multi-level user permissions (2 levels): management group and user group |
| Malfunction Detection |
Network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| PIP |
Yes (Intelligence automatically turns off when PIP is on) |
| Intelligence |
| Heat Detection |
Yes |
| Cold/Hot Spot Trace |
Yes |
| IVS (Perimeter Protection) |
Yes. Supports tripwire and intrusion. |
| Target Distinction |
Human/Vehicle Classification |
| Port |
| Analog Output |
1 × CVBS output; BNC port |
| Network Port |
1 × RJ-45 (10/100 Base-T) |
| Alarm Input |
2 |
| Alarm Output |
2 |
| Audio Input |
1 |
| Audio Output |
1 |
| RS-485 |
1 |
| Power |
| Power Supply |
Wide input voltage 10–36 VDC |
| Power Consumption |
Basic: 30 W (illuminator off, heating off)
Max: 43 W (illuminator on, heating off); 50 W (illuminator on, heating on) |
| Environment |
| Operating Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity |
≤95% |
| Storage Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
| Physical Characteristics |
| Protection |
IP66 |
| Reliability |
Surge protection: 6 kV
Air discharge: 15 kV
Contact discharge: 8 kV |
| Structure |
| Product Dimensions |
231.3 mm × 389.7 mm × 276.9 mm (9.11″ × 15.34″ × 10.9″) (L × W × H) |
| Packaging Dimensions |
485 mm × 360 mm × 390 mm (19.09″ × 14.17″ × 15.35″) (L × W × H) |
| Net Weight |
≤9 kg (19.84 lb) |
| Gross Weight |
≤12 kg (26.46 lb) |
| Heat Detection Distance |
| Focal Length |
Max. Distance |
| 7.5 mm |
440 m (1,443.57 ft) |
| 13 mm |
780 m (2,559.06 ft) |
| 25 mm/M25 mm |
1,500 m (4,921.26 ft) |
| 50 mm |
3,000 m (9,842.52 ft) |
| Note:
The table displays the measured distances obtained from using the target size 2 m × 2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.
The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
| Temperature Measurement Distance |
| Focal Length |
Min. Distance |
Max. Distance |
| 7.5 mm |
1 m (3.28 ft) |
6.5 m (21.33 ft) |
| 13 mm |
2 m (6.56 ft) |
11 m (36.09 ft) |
| 25 mm/M25 mm |
4 m (13.12 ft) |
21 m (68.90 ft) |
| 50 mm |
9 m (29.53 ft) |
42 m (137.80 ft) |
| Note:
The table displays the measured distances obtained from using the target size
0.1 m × 0.1 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.
The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
