| Thermal |
| Detector Type |
Vanadium oxide uncooled focal plane detector |
| Effective Pixels |
640 (H) × 512 (V) |
| Pixel Pitch |
12 μm |
| Spectral Range |
8 μm–14 μm |
| Sensitivity (NETD) |
≤35 mK |
| Focal Length |
26 mm–130 mm |
| Field of View |
26 mm–130 mm: H: 16.80–3.38°; V: 13.48°–2.71° |
| Focus Control |
Auto; Manual |
| Detection Distance? |
26 mm–130 mm: Vehicle: 1,6667 m (5,4681.76 ft);
Human: 5,417 m (17,772.31 ft) |
| Recognition Distance? |
26 mm–130 mm: Vehicle: 4,088 m (13,412.07 ft);
Human:1,393 m (4,570.21 ft) |
| Identification Distance? |
26 mm–130 mm: Vehicle: 2,064 m (6,771.65 ft);
Human: 696 m (2,283.46 ft) |
| Note:
?Detection Distance: Detects objects, but cannot recognize their characteristics (objects must cover more than 3.6 pixels of the image).
?Recognition Distance: Classifies objects into general categories, such as human, vehicle (the object must cover more than 14 pixels of the image).
?Identification Distance: Classifies objects into specific categories based on their characteristics, such as engineering truck, car (the object must cover more than 28 pixels of the image). |
| Digital Detail Enhancement (DDE) |
Yes |
| Image Stabilization |
Electronic Image Stabilization (EIS) |
| Digital Zoom |
24 levels |
| AGC |
Auto; Manual |
| Noise Reduction |
2D NR; 3D NR |
| Image Flip |
180° |
| Color Palettes |
18 (white hot; black hot; fusion; rainbow; globow; ironbow1; ironbow2; sepia; color1; color2; icefire; rain; red hot; green hot; spring; summer; autumn; winter) |
| Visible |
| Image Sensor |
1/1.8″ CMOS |
| Max. Resolution |
2688 (H) × 1520 (V) |
| Pixel |
4 MP |
| Min. Illumination |
Color: 0.005 lux
Black & white: 0.0005 lux
0 lux (IR on) |
| AGC |
Auto; Manual |
| Noise Reduction |
2D NR; 3D NR |
| S/N Ratio |
>55 dB |
| White Balance |
Auto; manual; indoor; outdoor; tracking; sodium lamp; street lamp; natural |
| Defog |
Optical defog |
| Image Stabilization |
Optical Image Stabilization |
| Electronic Shutter Speed |
1 s–1/30,000 s (auto/manual) |
| BLC |
Yes |
| WDR |
Yes |
| HLC |
Yes |
| Digital Zoom |
Yes |
| Day/Night |
Auto (ICR); Color; B/W |
| Image Flip |
180° |
| Exposure Compensation |
Yes |
| Focus Control |
Auto; semi-auto; manual |
| Focal Length |
6 mm–336 mm |
| Zoom Speed |
<8.8 s |
| Field of View |
H: 64.4°–1.28°
V: 38.37°–0.72° |
| Close Focus Distance |
0.1 m–5 m (0.33 ft–16.4 ft) |
| Optical Zoom |
56× |
| Aperture |
F1.5–F5.3 |
| Audio and Video |
| Video Compression |
H.265; H.264H; H.264 |
| Resolution |
Thermal:
Main stream: 1280 × 1024; 1280 × 960 ; 1280 × 720;
400 × 300; 1280 × 960 (default)
Sub stream: 640 × 512; 640 × 480; 400 × 300; 400 × 300 (default)
Visible:
Main stream: 2688×1520; 1920×1080; 1280×720;
704× 576; 2688 × 1520 (default)
Sub stream: 704 × 576; 352 × 288; 352 × 288 (default) |
| Video Frame Rate |
Thermal (50 Hz):
Main stream: 1 fps–50 fps, 50 fps by default
Sub stream: 1 fps–25 fps, 15 fps by default
Visible (50 Hz):
Main stream: 1 fps–25 fps, 25 fps by default
Sub stream: 1 fps–25 fps, 15 fps by default
Thermal (60 Hz):
Main stream: 1 fps–60 fps, 60 fps by default
Sub stream: 1 fps–30 fps, 15 fps by default
Visible (60 Hz):
Main stream: 1 fps–30 fps, 30 fps by default
Sub stream: 1 fps–30 fps, 15 fps by default |
| Audio Encoding |
G.711a; G.711mu; PCM |
| Image Encoding Format |
JPEG |
| PTZ |
| Pan/Tilt Range |
Pan: 0° to 360° endless
Tilt: –45° to +90° |
| Manual Control Speed |
Pan: 0.1°/s–140°/s
Tilt: 0.1°/s–50°/s |
| Preset Speed |
Pan: 0.1°/s–140°/s
Tilt: 0.1°/s–50°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Power-off Memory |
Yes |
| Privacy Masking |
4 blocks |
| Idle Motion |
Preset; auto pattern; auto tour; pan; progressive scan |
| Timing Task |
Preset; auto pattern; auto tour; pan; progressive scan |
| Position Display |
ON/OFF |
| Preset Video Freeze |
Yes |
| Telephoto Speed Limit |
Yes |
| Positioning Accuracy |
± 0.1° |
| Wiper |
Manual/Auto. Supports setting wiper running times, frequency, and period |
| 3D Positioning |
Yes |
| IR Illumination |
| IR Illumination Distance |
300 m (984.26 ft) |
| IR Illuminator On/Off Control |
Auto; Manual |
| Function |
| Two-way Audio |
Yes |
| Network Protocol |
HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP; Multicast; SFTP; 802.1x |
| Region of Interest (RoI) |
Yes (customizable) |
| Storage |
FTP; Micro SD card (optional) |
| Interoperability |
ONVIF; CGI; DaHuaSDK |
| Browser |
IE: IE8 and later (includs the browsers with IE kernel, such as 360 Explorer, Sougou Explorer)
Chrome: 42 and earlier
Firefox: 42 and earlier |
| User/Host |
Up to 12 (total bandwidth: 64 MB) |
| Security |
Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access |
| User Management |
Up to 20 users; supports multi-level user permissions (2 levels): management group and user group |
| Malfunction Detection |
Network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| PIP |
Yes |
| Intelligence |
| Heat Detection |
Yes. Marks the detected anomaly. |
| Cold/Hot Spot Trace |
Yes |
| Perimeter Protection |
Yes. Supports tripwire and intrusion. |
| Target Distinction |
Human/Vehicle Classification |
| Target Filtering |
Yes |
| Target Tracking |
Yes |
| Smoke Detection |
Yes |
| Boat Detection |
Yes |
| Port |
| Analog Output |
1 × CVBS output; BNC port |
| Network Port |
1 × RJ-45 (10/100 Base-T) |
| Alarm Input |
7 |
| Alarm Output |
2 |
| Alarm Event |
No SD card; low SD card space; SD card error; network disconnection; IP conflict; motion detection; video tampering; intrusion; tripwire; audio detection; defocus on thermal channel |
| Audio Input |
1 |
| Audio Output |
1 |
| RS-485 |
1 |
| Power |
| Power Supply |
Wide input voltage 24–57 VDC |
| Power Consumption |
Basic: 39 W (illuminator off, heater off)
Max: 76 W (illuminator on, heater off);
99 W (illuminator on, heater on) |
| Environment |
| Operating Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity |
≤95% |
| Storage Temperature |
–40 °C to +70 °C (32 °F to +158 °F) |
| Physical Characteristics |
| Protection |
IP66 |
| Product Dimensions |
597 mm × 290 mm × 427 mm (23.5″ × 11.41″ × 16.81″) (L × W × H) |
| Packaging Dimensions |
722 mm × 675 mm × 443 mm (28.43″ × 26.57″ × 17.44″) (L × W × H) |
| Net Weight |
≤25 kg (55.11 lb) |
| Gross Weight |
≤35 kg (77.15 lb) |
| Installation |
Desk mount |
| Power Adapter |
Included |
| Lens |
Included |
| PTZ Outlet |
Side |
| Certification |
| Certifications |
CE; FCC |
| Heat Detection Distance |
| Focal Length |
Max. Distance |
| |
|
| 26 mm-130 mm |
7,800 m (25,590.55 ft) |
| Note:
The table displays the measured distances obtained from using the target size 2 m × 2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.
The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
| Perimeter Protection Distance |
| Focal Length |
Distance (Human) |
Distance (Vehicle) |
| |
|
|
| 26 mm–130 mm |
910 m (3,022.71 ft) |
2,730 m (8,956.69 ft) |
| Note:
The table displays the measured distances obtained from using the target sizes
1.8 m × 0.5 m (human) and 1.4 m × 4 m (vehicle) for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.
The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
