Features
Technical
· High sensitivity, omnidirectional microphone head, and omnidirectional microphone for clear and natural sound.
· Lightning protection, power polarity reversal protection, and electrostatic protection.
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scope | 10~70 m2 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sensitivty | -34±3dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frequency response | 80Hz~16kHz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DirectionL characteristic | Omni-directional | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SNR (re 94dBSPL = 1Pa@1KHz) | 58dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dynamic range | 74dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. sustainable sound pressure | 110dBSPL (1KHz, THD 1%) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output impedance | 600Ω(non-equilibrium) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output signal amplitude | 2.5Vpp/88dBSPL | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Microphone | Plated film capacitor microphone head | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working voltage | DC 12V | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working current | 40mA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working temperature | -30°C~+70ºC(-22℉~+158℉) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Material | Aluminum | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color | Silver | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension | Φ40mm×20mm (Φ1.57”×0.79”) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight | 48g (0.11Ib) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | CE/FCC |
