| System |
| Main Processor |
64-bit high-performance multi-core processor |
| Operating System |
Embedded Linux OS |
| Operating Interface |
Web (PCAPP) |
| Controller |
Single controller₩Single controller |
| Cache |
16 GB by default (extendable to 128 GB) |
| Camera Compatibility |
| Thermal |
Works with camera for fire alarm, temperature alarm, temperature difference alarm, hot spot, cold spot, smoking and calling |
| People Counting |
Works with camera for tripwire people counting, regional people counting and queue people counting |
| Bullet-PTZ Smart Track |
Works with camera for manual tracking, auto tracking, click positioning and select positioning |
| Fisheye Dewarp |
Supports dewarping for fisheye cameras |
| Cluster |
| Cluster |
N+M |
| Audio and Video |
| Third-party Camera Access |
Onvif,Onvifs,RTSP,Sony,Panasonic,Axis,Arecont,Pelco,Canon,Samsung,Hikvision |
| Compression Standard |
| Video Compression |
Smart H.265+;H.265;Smart H.264+;H.264;MJPEG |
| Audio Compression |
G.711a;G.711u;G.729;AAC;G.726;MP2L2;G.7221 |
| Network |
| Network Protocol |
HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;iSCSI;FTP;SMB;NFS;GAT1400 |
| Interoperability |
ONVIF (Profile S); CGI; SDK |
| Browser |
Chrome; PCAPP; IE9 or higher; Firefox |
| Network Mode |
Multiple-address mode;Load balance;Fault-tolerance;Link aggregation |
| Recording Playback |
| Multi-channel Playback |
Max. 16-channel playback |
| Record Mode |
Auto record; manual record; search video detection; IO alarm; thermal imaging; intelligent event; all record file |
| Storage Method |
Internal HDD and network disk |
| Backup Method |
HDD, peripheral USB storage device |
| Playback Function |
1. Play, pause, stop, fast forward, fast backward, reverse play, frame by frame 2. Full-screen, backup (clip; file), snapshot, digital zoom, audio on; off |
| Storage |
| Video Direct Storage (Private Protocol) |
Incoming: 1024-channel (bandwidth: 2048 Mbps) Recording: 1024-channel (bandwidth: 2048 Mbps) Outgoing: 1024-channel (bandwidth: 2048 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) |
| Video Direct Storage (Onvif) |
Incoming: 1024-channel (bandwidth: 2048 Mbps)
Recording: 1024-channel (bandwidth: 2048 Mbps)
Outgoing: 1024-channel (bandwidth: 2048 Mbps)
Playback: 32-channel (bandwidth: 64 Mbps) |
| Video Direct Storage (Auto Register) |
Incoming: 1024-channel (bandwidth: 2048 Mbps) Recording: 1024-channel (bandwidth: 2048 Mbps) Outgoing: 1024-channel (bandwidth: 2048 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) |
| Video Direct Storage (International Protocol) |
Incoming: 1024-channel (bandwidth: 2048 Mbps) Recording: 1024-channel (bandwidth: 2048 Mbps) Outgoing: 1024-channel (bandwidth: 2048 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) |
| Picture Direct Storage |
Incoming: 512-channel (550 KB/picture） Recording: 512-channel (550 KB/picture） Outgoing: 512-channel (550 KB/picture） |
| Disk Group |
Yes |
| iSCSI |
Supports client and Server |
| Network Disk |
Supports client |
| RAID |
RAID0;RAID1;RAID5;RAID6;RAID10;RAID50;RAID60;JRAID |
| Record Management |
Supports record control (continuous, event-based, scheduled, scheduled & event-based). |
| Storage Pool |
Yes |
| IPSAN |
| IPSAN Performance |
Write-through: 900 Mbps Write-back: 1200 Mbps |
| Alarm |
| General Alarm |
Motion detect; tampering; IPC external alarm |
| Anomaly Alarm |
IPC offline alarm; storage error; HDD full; video frame loss; SSD exception; IP conflict; MAC conflict; login lock; fan malfunction; no HDD; network security exception; power exception; disk health exception; RAID exception; storage pool exception; temperature alarm; share service |
| Alarm Linkage |
Record; snapshot (full image); alarm uploading; remote device alarm output; camera audio; buzzer; log; preset; email, smart tracking and warning light. Disarming alarm linkage action by period or one-click sync disarm config with channels |
| Port |
| Disk Interface |
85 slots,
SATA; SAS,
Max.20 TB/HDD ,
hot swapping, CMR,
support enterprise-grade HDD |
| eSATA |
1 port |
| RS-232 |
1 port, for debug or COM data transmission |
| USB |
2 ports. 2 USB3.0 ports at the rear panel |
| Network Port |
4 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports. (gigabit electrica port)
1 RJ-45 10/100 Mbps self-adaptive Ethernet ports. (100 Mbps electrical port) |
| Power |
2+1 redundant power supply |
| Network Port Extension |
2 × 10-GbE optical fiber ports (optional) |
| General |
| Disk Bay |
85 |
| Form Factor |
4U |
| Power Supply |
100–127/200–240 VAC, 50/60 Hz, 16/8A |
| Power Consumption |
<1600 W (include disks) |
| Fan |
Intelligent speed regulation fan |
| Net Weight |
55.2kg (121.7 lb) |
| Gross Weight |
75kg (165.3 lb) |
| Product Dimensions |
Chassis:446mm x 177mm x 932.9mm (17.56″ × 6.96″ × 36.73″) (W × H × D) |
| Packaging Dimensions |
With packaging:482.6mm x 177mm x 932.9mm (19″ × 6.96″ × 36.73″) (W × H × D) |
| Operating Temperature |
0°C to +35°C (+32℉ to +95℉) |
| Operating Humidity |
10%–80% (RH), non-condensing |
| Operating Altitude |
≤3000m |
| Installation |
Standard 19 inch rack, with slide rail |
| Certifications |
CE: CE-LVD: EN 62368-1/IEC 62368-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130-4, EN 55035 FCC: Part 15 Subpart B |
