| Camera |
| Image Sensor |
1/2.7″ inch CMOS |
| Max. Resolution |
2880 (H) × 1620 (V) |
| Pixel |
5MP |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s |
| Min. Illumination |
0.005 Lux/F1.6, 30IRE, 0 Lux IR on |
| Illumination Distance |
80 m (262.5 ft) |
| Illumination On/Off Control |
Auto; manual |
| Illuminator Number |
2 |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm; 6 mm; 8 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8 mm: 132° × 111° × 58°
(diagonal × horizontal × vertical)
3.6 mm: 109° × 92° × 48°
(diagonal × horizontal × vertical)
6 mm: 65° × 57° × 30° (diagonal × horizontal × vertical)
8 mm: 48° × 43° × 24° (diagonal × horizontal × vertical) |
| Iris Type |
Fixed iris |
| Close Focus Distance |
2.8 mm: 0.9 m
3.6 mm: 1.6 m
6 mm: 3.1 m
8 mm: 4.9 m |
| DORI Dıstance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
63.6 m |
25.4 m |
12.7 m |
6.4 m |
| 3.6 mm |
80 m |
32 m |
16 m |
8 m |
| 6 mm |
120 m |
48 m |
24 m |
12 m |
| 8 mm |
150.4 m |
60.2 m |
30.1 m |
15 m |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
| Video |
| Frame Rate |
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H |
| Resolution |
5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480) |
| Day/Night |
Auto swtich by ICR |
| BLC |
BLC/HLC/DWDR |
| WDR |
DWDR |
| White Balance |
Auto; manual |
| Gain Control |
Auto; manual |
| Noise Reduction |
2D NR |
| Smart IR |
Yes |
| Mirror |
Off/On |
| Privacy Masking |
Off/On (8 areas, rectangle) |
| Certifications |
| Certifications |
CE (EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015, EN 55035:2017, EN 50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Audio Interface |
One channel built-in mic |
| Video Output |
Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Power |
| Power Supply |
12V ±30% DC |
| Power Consumption |
Max 5.2W (12V DC, IR on) |
| Environment |
| Operating Temperature |
–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation) |
| Storage Temperature |
–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Mental front cover+plastic main body+plastic bracket |
| Camera Dimensions |
198.9 mm × 80.2 mm × 76.2 mm ( 7.83″ × 3.16″ × 3.00″ ) |
| Net Weight |
0.27kg (0.60lb) |
| Gross Weight |
0.46kg (1.01lb) |
