| Camera |
| Pixel |
5MP |
| Image Sensor |
5MP CMOS |
| Max. Resolution |
2880 (H) × 1620 (V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1/3 s–1/100000 s
NTSC: 1/4 s–1/100000 s |
| Min. Illumination |
0.001 [email protected] (Color, 30 IRE)
0.0001 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on) |
| S/N Ratio |
>65 dB |
| Illumination Distance |
IR: 40 m (131.23 ft)
Warm light: 40 m (131.23 ft) |
| Illuminator On/Off Control |
Auto; manual |
| Illuminator Number |
2 (IR light) |
| 2 (Warm light) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.0 |
| Field of View |
2.8 mm: H: 111°; V: 57°; D: 131°
3.6 mm: H: 89°; V: 47°; D: 104° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.8 mm: 1.5 m (4.92 ft)
3.6 mm: 2.2 m (7.22 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
66.0 m
(216.54 ft) |
26.4 m
(86.61 ft) |
13.2 m
(43.31 ft) |
6.6 m
(21.65 ft) |
| 3.6 mm |
78.0 m
(255.91 ft) |
31.2 m
(102.36 ft) |
15.6 m
(51.18 ft) |
7.8 m
(25.59 ft) |
| Video |
| Video Frame Rate |
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps;
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps;
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H |
| Resolution |
5M (2880 × 1620);
4M (2560 × 1440);
1080p (1920 × 1080);
960H (960 × 576/960 × 480) |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
BLC; HLC; WDR; HLC-Pro |
| WDR |
120dB |
| White Balance |
Auto; Area white balance |
| Gain Control |
Auto; manual |
| Noise Reduction |
3D NR |
| Illumination Mode |
Smart IR&WL; WL Mode; IR Mode |
| Defog |
Electronic defog |
| Digital Zoom |
4× |
| Mirror |
Yes |
| Privacy Masking |
Off/On (8 areas, rectangle) |
| Active Deterrence |
| Sound Warning |
Audio 1: Alarm
Audio 2: No parking here
Audio 3: Private land no entry.
Audio 4: Warning zone keep off
Audio 5: Welcome
Volume: high/medium/low;
duration: 5 s–60 s; 110 dB |
| Red/Blue Light Warning |
Flash: 5 s–60 s; frequency: high/medium/low |
| Certification |
| Certifications |
CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14) |
| Port |
| Video Output |
Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input |
One channel built-in MIC |
| Alarm Output |
1 channel |
| Power |
| Power Supply |
12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera) |
| Power Consumption |
Max 10.5W (12 VDC, LED on) |
| Environment |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to 140 °F) |
| Operating Humidity |
<95% (RH), non-condensing |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to 140 °F) |
| Protection |
IP67 |
| Structure |
| Casing Material |
Metal front cover + plastic rear barrel + metal bracket |
| Product Dimensions |
240.7 mm × Φ90.7 mm (9.48″ × Φ3.57″) |
| Packaging Dimensions |
299 mm × 119 mm × 111 mm (11.77″ × 4.69″ × 4.37″) |
| Net Weight |
0.48 kg (1.06 lb) |
| Gross Weight |
0.74 kg (1.63 lb) |
| Installation |
Wall mount; ceiling mount; vertical pole mount |
