| Camera |
| İmage Sensor |
1/2.7″ CMOS |
| Max. Resolution |
2592 (H) × 1944 (V) |
| Pixel |
5MP |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s |
| S/N Ratio |
>65 dB |
| Min. Illumination |
0.005 Lux/F1.2, 0 Lux warm light on |
| Illumination Distance |
40 m (131.2 ft) |
| Illumination Type |
Warm light |
| Illumination On/Off Control |
Auto; Manual |
| Illumination Number |
2 (Warm light) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–180°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed- Focus |
| Mount Type |
M12 |
| Focus Length |
3.6 mm; 6 mm |
| Max. Aperture |
3.6 mm: F1.2
6 mm: F1.2 |
| Field of View |
3.6 mm: H: 83°; V: 60°; D: 112°
6 mm: H: 53°; V: 40°; D: 66° |
| Iris Type |
Fixed Iris |
| Close Focus Distance |
3.6 mm: 1.9 m (6.23 ft)
6 mm: 4.5 m (14.76 ft) |
| DORI Mesafesi |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 3.6 mm |
77.8 m (255.3 ft) |
31.1 m (102.0 ft) |
15.6 m (51.2 ft) |
7.8 m
(25.6 ft) |
| 6 mm |
120 m (393.7 ft) |
48 m
(157.5 ft) |
24 m
(78.7 ft) |
12 m
(39.4 ft) |
| Video |
| Frame Rate |
CVI:
5M@20 fps, 4M@25 fps/30 fps, 1080p@25 fps/30 fps;
AHD:
5M@20 fps;
TVI:
5M@20 fps;
CVBS:
960H |
| Resolution |
5M (2592 × 1944); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |
| BLC Mode |
BLC/HLC/DWDR |
| WDR |
DWDR |
| White Balance |
Auto/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D |
| Smart Light |
Yes |
| Mirror |
Off/On |
| Privacy Masking |
Off/On (8 Area, Rectangle) |
| Certifications |
| Certifications |
CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
IEC 62368-1:2014 (Second Edition) |
| Port |
| Video Output |
1 BNC output
support CVI/TVI/AHD/CVBS |
| Alarm Output |
1ch alarm out |
| Active Deterrence |
| Red/Blue Light Warning |
Flash: 5 s–30 s; frequency: high/medium/low |
| Sound Warning |
Audio 1/2/3; Volume: high/medium/low;
duration: 5 s–30 s; 110 dB |
| Power |
| Power Supply |
12V ±30% DC |
| Power Consumption |
Maks 7.7W (12V DC, warm light on) |
| Environment |
| Operating Temperature |
–40°C to +60°C (–40°F to 140°F);
<95% (non-condensation) |
| Storage Temperature |
–40°C to +60°C (–40°F to 140°F);
<95% (non-condensation) |
| Ingress Protection |
IP67 |
| Structure |
| Casing |
Cover: Metal
Rear: Plastic
Pedestal: Plastic |
| Camera Dimensions |
240.7 mm × Φ90.7 mm (9.48″ × Φ3.57″) |
| Net Weight |
0.44 kg (0.97 lb) |
| Gross Weight |
0.70 kg (1.54 lb) |
